Alienware 17 Ssd Slots
I have an Alienware 17 R3 from 2016. Does anyone know if this PCI Express 3.0 X2 SSD will work in this system? The 2nd available M.2 NVMe Slot in the computer consists of a PCI Express 3.0 X2 Interface but I am not sure about anything else. If not does anyone know the fastest expansion SSD that can be put into an Alienware 17 R3 from 2016. This guide will show you how to access and remove the solid state drive (SSD) for your Alienware 17 R4. Buy these tools. Phillips Head Screwdriver: Size PH1.
- The Alienware 17 has four total memory slots; these are the first two. The others, as well as the mSATA SSD, are located under the keyboard, which is described in the next section.
- Inside Alienware 17 R4 – disassembly, internal photos and upgrade options says The motherboard holds three M.2 PCIe NVMe-enabled SSD slots with one in our unit taken by a Toshiba M.2 PCIe NVMe SSD with 256GB capacity while the 2.5-inch HDD slot is taken by an HGST drive with 1TB capacity.
In this guide, I will disassemble an Alienware 17 R4. I will remove the bottom cover to upgrade the SSD, HDD, and RAM.
For the freshest produce, find us on Facebook for the latest teardown news.
There are two different types of screws, and I circled them with different colors.
Remove six screws (red) that securing the bottom cover to the laptop.
Loosen one screw (yellow). Insert a pick to pry up the bottom cover.
Under the bottom cover, you can get access to three M.2 SSD slots, two RAM slots, and a hard drive module.
From the picture you can see, Alienware 17 R4 comes with two M.2 2280 SSD slots (support SATA and PCIe SSD) and an M.2 2242 slot.
Here’s left the cooling fan.
The Alienware 17 R4 comes with two 8GB DDR4 2667MHz RAMs. According to Dell website information, it supports up to 32GB RAM, so you can replace it with 16GB DDR4 2667MHz RAM respectively.
Alienware 17 R4 Ssd Slots
Here’s hard drive module, it is securing to the laptop by four screws.
Alienware 17 R5 Ssd Slots
Here’s Toshiba 256GB PCIe SSD.
